Reduced Shank Drill 22mm 1/2"
Stock Code:
2654-22.00
Price:
$119.94
| Diameter (mm) | 22 |
| Flute Length (mm) | 89 |
| Overall Length (mm) | 152 |
| Pack Quantity | 1 |
| Spindle Speed Stainless Steel RPM | 174 |
| Spindle Speed Tool Steel RPM | 261 |
| Spindle Speed Cast Iron RPM | 347 |
| Spindle Speed Malleable Iron RPM | 391 |
| Spindle Speed Med. Carbon Steel RPM | 434 |
| Spindle Speed Free Cutting Steel RPM | 623 |
| Spindle Speed Aluminium/Brass RPM | 883 |
| Spindle Speed Wood/Plastic RPM | 1317 |
| Feed per revolution mm | 0.41 |
BORDO REDUCED SHANK HSS DRILLS
118° notched point 30° helix
DRILL BIT SURFACE TREATMENT
Bordo reduced shank HSS drills are ground and then a black finish is achieved by steam tempering, a thermal process resulting in a porous tool coating. This surface aids chip flow and heat dissipation. The drill is then ground a second time to achieve a bright finish on the shank and cutting edges.
